VOOPOO PnP X Pod Tank 5ml – DTL & MTL
The VOOPOO PnP X Pod Tank is a 5ml refillable 510 tank built around VOOPOO’s PnP X coil platform. It is available in separate DTL and MTL versions, with top airflow, side filling and a 510 base for use on compatible regulated mods.
Important compatibility note: this tank uses PnP X coils, not the older VOOPOO PnP coil series.
Choose the Correct Version
| Black DTL / Grey DTL |
Open direct-to-lung draw. Compatible with the full PnP X coil platform. Supplied with 0.15Ω and 0.3Ω PnP X coils. |
| Black MTL |
Tighter mouth-to-lung draw with replaceable 510 MTL drip tip. Designed for PnP X 0.3Ω and 0.6Ω coils. |
Official Specifications
-
Capacity: 5ml
-
Filling: Side fill
-
Airflow: Adjustable top airflow
-
Material: PCTG + stainless steel
-
Connection: Standard 510
-
DTL size: Ø26 × 53.9mm
-
MTL size: Ø26 × 60mm
DTL Version
-
Standard coils: PnP X 0.15Ω + PnP X 0.3Ω
-
Compatible coils: All VOOPOO PnP X coils
-
0.15Ω: 60–80W
-
0.3Ω: 32–40W
-
Recommended e-liquid: 50–70% VG, up to 10mg nicotine
-
Drip tip: Fixed DTL mouthpiece
MTL Version
-
Standard coils: PnP X 0.6Ω + PnP X 0.3Ω
-
Compatible coils: PnP X 0.3Ω and 0.6Ω
-
0.6Ω: 18–23W
-
0.3Ω: 32–40W
-
Recommended e-liquid: 50% VG, up to 35mg nicotine
-
Drip tip: Replaceable PnP X 510 MTL drip tip
What’s in the Box?
DTL version: 1 × PnP X Pod Tank DTL 5ml, 1 × PnP X 0.15Ω coil, 1 × PnP X 0.3Ω coil, 1 × user manual.
MTL version: 1 × PnP X Pod Tank MTL 5ml, 1 × replaceable PnP X 510 MTL drip tip, 1 × PnP X 0.6Ω coil, 1 × PnP X 0.3Ω coil, 1 × user manual.
How to Set It Up
- Install the correct PnP X coil firmly into the pod tank.
- Open the side-fill port and fill the tank to approximately two-thirds capacity.
- Close the silicone fill plug securely.
- Allow a new coil to stand for about 5 minutes before first use so the cotton can saturate.
- Start at the lower end of the coil’s recommended wattage range and adjust gradually.
FAQ
Does this use normal VOOPOO PnP coils?
No. The PnP X Pod Tank is designed for the newer PnP X coil platform.
Can I use it on a standard box mod?
Yes. The complete PnP X Pod Tank has a standard 510 connection and VOOPOO lists it as compatible with 510-base mods.
What is the difference between DTL and MTL?
The DTL version has a more open draw and supports the full PnP X coil range. The MTL version has a tighter draw, a replaceable 510 MTL drip tip and is designed around the 0.3Ω and 0.6Ω PnP X coils.
Is this the same as the PnP X cartridge for the DRAG S2/X2?
No. The cartridge version is designed to fit compatible pod devices directly. This listing is for the PnP X Pod Tank with a 510 base.
